status in KNX

Haritz Goikoetxea 1 month ago in Devices / KNX • updated 1 month ago 2

Hello friends!

I am a beginner with the Comfortclick and I have a simple question about the status of the devices. Where can I configure the status? I just found the parameter value.

The same thing happened to me with other kind of devices like temperature setpoints, shades, and more things...

Thanks a lot!

Haritz

0

Use KNX-pushbutton to activate a scene

Smets Ben 3 months ago in Devices / KNX • updated by Fredrik Sandblom 3 months ago 1

Hello,

I looking for a way to activate a scene from Comfortclick with a KNX-pushbutton in a project that i'm working on.

Any ideas how i can use the button as a trigger for a scene?

0
Under review

Jigsaw knx physical address

Enric Nadal 4 months ago in Devices / KNX • updated by ComfortClick Support 3 months ago 1

Hi,

I've configured the physical address in knx for a Jigsaw to be 1.1.63, as the last device before a line repeater.

The issue is that when I open the bus monitor in ETS, I see a lot of traffic coming from 1.1.64, which is the line repeater, but corresponds to the Jigsaw.

Why isn't it using the address I configured?

Thanks in advance

0

KNX IP secure

Noel Fuentes 4 months ago in Devices / KNX • updated by Freud Tachy 2 months ago 2

Hi!

I didn't have a chance to test it, but has anyone tried Comfortclick with KNX IP secure routers/interfaces?

Thanks in advance.

Best regards

0

Configuration for blinds in bOS Configurator

Andrej Tibaut 5 months ago in Devices / KNX • updated 5 months ago 4

Hello CC users,

where can I find guidelines for configuration of KNX blinds (as seen in the demo project)?

0

bOS Values for 1byte are different in KNX

Jürgen Jürgenson 5 months ago in Devices / KNX • updated 5 months ago 2

Hey,

Our client wanted to change ventilation speeds from the thermostat. Ventilation runs on Modbus everything else is on KNX bus.

This may be a really stupid question but... i found that when i put a value for 1byte in bOS 1 then KNX sees it as 3 and value 2 as 5. But in bOS it shows the correct values. Ventilation has 3 speeds that we control (0 is for away, 1 is home, 2 is guests) I made some screenshots.
In bOS

Shows as correct value in bOS

But in KNX sees it as 3 and value 2 as 5 in knx


Is this normal or am i missing something?

I got it working though by changing the values in the Thermostat to 3 and 5, there is no problem with value 0 :) . So now every thermostat shows the correct status and from every thermostat they can change the ventilation speeds. But I find it weird that it changes the values like that.

Best regards.

0
Under review

reduce max brightness during night?

Dave De Busschere 5 months ago in Devices / KNX • updated 5 months ago 2

Hi,

I want to reduce the maximum brightness (of lights in a group) to 50% instead of 100% during night.

Anyone an idea how to configure this?

0
Under review

buttons & lighting "night mode"

Dave De Busschere 6 months ago in Devices / KNX • updated 6 months ago 5

Hello,

I'd like to use the night mode in the buttons (light up and night).

and at the same time i wan't to have the lighting in the bedroom area (toilet, bedrooms, halway,..) to work at ca. 40%.

All lights are DALI dimmable.

I made a group 3/3/4 night buttons where i put the 4(general) LED - brightness mode in.

What do i have to do in bosconfig for the nightmode buttons and what for the lights to go max. 40%?


Thanks,

0

Reading signal (Status) for a KNX 4 binary input

Aladdin Aladdinsultan 6 months ago in Devices / KNX • updated 6 months ago 4

Hi dears,,

I have an important question,, so plz help to answer it,,

I have hotel project,, the owner needs to know if the rooms are (occupied / empty) as a simple solution, using a KNX 4 binary input modules,,


so my question is can i integrate these knx modules with jigsaw, to read/know each room status as (occupied /empty)??

Note: in this KNX system,  I will use KNX Power Supply and KNX 4 binary input modules..

Regards,,

Aladdin Sultan


0

KNX Dali Gateway

Dave De Busschere 6 months ago in Devices / KNX • updated by Fredrik Sandblom 6 months ago 13

I have some some dimming lights (controlled buy dali gateway), they are programmed in ETS and working fine.

Now i'm trying to control theme with comfort click without succes.

I have the following adresses:

3/4/0 switch (switch)

3/4/1 dimming (dimming control)

3/4/2 value (percentage 0-100%)

3/4/3 status (switch)

I used in comfort click the following adress:

Address: 3/4/0 switch

status address: 3/4/2

resutl:

the slide goes directly back to 0

the light does nothing
